MAINBOARD (AM4) BIOSTAR B550MT DDR4
Original price was: ฿2,500.00.฿2,450.00Current price is: ฿2,450.00.
BIOSTAR :
-
MAINBOARD (AM4) BIOSTAR B550MT DDR4
MAINBOARD (AM4) BIOSTAR B550MT DDR4
รายละเอียดสินค้า :
- Support CPU : AMD Ryzen 3rd Gen (Matisse/ Renoir) and Ryzen 4th Gen (Vermeer/ Cezanne) processors
- From Factor : Micro ATX
- Chipset : AMD B550 Chipset
- Memory Channel : Dual Channel DDR4 2DIMM
- Memory Support : up to 4400(O.C.)
- Memory MAX : 64GB
- M.2 Slot : 1 slot
- SATA III 6G : 4 ports
- PCIe 4.0×16 : 1 slot
- Lan Port : 1 Gigabit LAN
| Brand | BIOSTAR |
| Model | B550MT |
| CPU Support | Socket AM4 support AMD Ryzen™ 3rd Gen (Matisse/ Renoir) and Ryzen™ 4th Gen (Vermeer/ Cezanne) processors
Support for future AMD Ryzen processors with BIOS update * Please refer to www.biostar.com.tw for CPU support list. |
| CPU Brand | AMD |
| Socket | AM4 |
| Chipset | AMD B550 |
| Memory Support | 4th Gen AMD Ryzen Processors (Vermeer CPUs): Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/2133 4th Gen AMD Ryzen with Radeon Graphics Processors (Cezanne APUs): 3rd Gen AMD Ryzen Processors (Matisse CPUs): 3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs): 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory * Please refer to www.biostar.com.tw for Memory support list. |
| Maximum Memory Bus | 4400 |
| Graphics | By CPU model Supports DX12 Supports HDCP |
| Multi Graphic Support | N/A |
| Audio | ALC897 7.1 Channels, High Definition Audio, Hi-Fi (Front) |
| Expansion Slots | AMD Ryzen 5000/3000 Series Processors 1 x PCIe 4.0 x16 Slot (x16 or x4/x4/x4/x4 mode) or AMD Ryzen 5000 G/4000 G Series Processors 1 x PCIe 3.0 x16 Slot (x16 or x8/x4/x4 mode) AMD B550 Chipset * According to different CPUs will have different speeds. |
| Maximum PCIe Version | PCIe 4.0 |
| Storage | Total supports 1 x M.2 socket and 4 x SATA III (6Gb/s) ports
1 x M.2 (M Key) Socket (M2M_CPU): Supports PCIe 4.0 x 4 (64Gb/s) & SATA III (6.0Gb/s) SSD Supports PCIe 3.0 x 4 (32Gb/s) & SATA III (6.0Gb/s) SSD 4 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10 * M.2 (M2M_CPU) Socket: The bandwidth is depended on CPU. Supports PCIe 4.0 x 4 (64Gb/s) speed, which depends only on Ryzen 3rd Gen Matisse & 4th Gen Vermeer. |
| M.2 Storage Type Support | NVMe |
| M.2 Slot | 1 |
| USB | 1 x USB 3.2 (Gen2) Type-C port (1 via internal headers) 6 x USB 3.2 (Gen1) ports(4 on rear I/Os and 2 via internal headers) 6 x USB 2.0 ports (2 on rear I/Os and 4 via internal headers) |
| Internal I/O Connectors | 4 x SATA III (6.0Gb/s) Connectors 2 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) 1 x USB 3.2 (Gen2) Type-C Header 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Internal Stereo Speaker Header 1 x Clear CMOS Header 1 x COM Port Header 1 x TPM Header |
| Back Panel Connectors | 1 x DP Port 1 x HDMI Port 1 x LAN port 4 x USB 3.2 (Gen1) Ports 2 x USB 2.0 Ports 3 x Audio Jack |
| LAN | Realtek RTL8111H 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability |
| Wireless Data Network | None |
| Form Factor | Micro ATX |
| H/W Monitoring | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring |
| BIOS | N/A |
| Special Features | N/A |
| Software Features | BullGuard |
| Operating System Support | Supports Windows 10(64bit)/ 11(64bit)
*Biostar reserves the right to add or remove support for any OS with or without notice. |
| Package Contents | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
| สี | Black, White |
|---|
